1.5mm 2 Pin TE Automotive Connectors Housing

1.5mm 2 Pin TE Automotive Connectors Housing
1.5mm 2 Pin TE Automotive Connectors Housing 1.5mm 2 Pin TE Automotive Connectors Housing 1.5mm 2 Pin TE Automotive Connectors Housing

Large Image :  1.5mm 2 Pin TE Automotive Connectors Housing

Product Details:

Place of Origin: China
Brand Name: TE Connectivity/AMP
Certification: Rohs
Model Number: 282080-1

Payment & Shipping Terms:

Minimum Order Quantity: 1200
Price: 0.45$
Packaging Details: Original packing
Delivery Time: 1-12 weeks
Payment Terms: T/T
Supply Ability: 48000
Detailed Product Description
In Stock Qty:: 4800 Stock Lead Time: 4-7 Days
Packing Qty:: 1200 Common Lead Time: 8 Weeks
Decription: TE Connectivity AMP Connector Wire To Wire Contact AMP Superseal 1.5mm Series Housing 2 Pin Plug 282080-1 Stock Price: Reduce As Quantity Increase
High Light:

te connectivity connectors

,

amp terminal connectors

TE Connectivity AMP Connector Wire to Wire Contact AMP Superseal 1.5mm Series Housing 2 Pin Plug 282080-1​



Description:



TE Connecitivty has deve l oped the AMP SUPERSEAL 1.5 series con nector family to meet the increasing re quire ments for reliability and water proofness. AMP SUPERSEAL 1.5 series con nector exceed the requirements prescribed by IP 67 accord ing IEC 60529 and DIN 40050-9 stand ards and has its appli cation in the auto motive, agri culture and industrial machinery. For sensor ap pli cation the AMP SUPERSEAL 1.5 series Con nector system is qualified as well.

Advantages
  • Compact system minimizes packaging requirements
  • Sealing reliability proven under harsh conditions
  • Designed for ease of manual harness assembly, engine mounting and under hood environments

Applications
  • Wire-to-Wire (1.5 mm) and ECU applications, under hood or any location where sealing is required
  • Suit able for automotive, truck, bus, or off-road vehicles

RoHS Compliant
Part numbers in this catalog are RoHS Compliant, unless marked otherwise. These products comply with European Union Directive 2002/95/EC as amended 1 January 2006 that restricts the use of lead, mercury, cadmium, hexavalent chromium, PBB, and PBDE in certain electrical and electronic products sold into the EU as of 1 July 2006. Note: For purposes of this Catalog, included within the definition of RoHS Compliant are products that are clearly “Out of Scope” of the RoHS Directive such as hand tools and other non-electrical accessories.

Specification:

AMP Connector 282080-1
Connector Style Housing for female terminals
Connector System Wire-to-Board,Wire-to-Device, Wire-to-Wire
Number of Positions 2
Operating Voltage (VDC) 24
Color Black
Cable Exit Angle 180°
Body Material PA GF
Mating Tab Width 1.5 mm [ .059 in ]
Centerline (Pitch) 6 mm [ .236 in ]
Operating Temperature Range -40 – 125 °C [ -40 – 257 °F ]
Width 9.3 mm [ .366 in ]
Height 32.2 mm [ 1.268 in ]
Length 17.1 mm [ .673 in ]





Related products:

Female Receptacle 282104-1, 282104-2, 282104-3
Terminal 282110-1, 282403-1, 282466-1
Male Plug 282080-1, 282080-2, 282080-3
Wire Seal 281934-2, 281934-3, 281934-4,282081-1



AMP Superseal 1.5MM Series:

1.5mm 2 Pin TE Automotive Connectors Housing 0

POSITION Female Male
1 PIN-black/gray 282079-1,282079-2, 1-282079-2 282103-1, 282103-2
2 PIN-black/gray 282080-1, 282080-2 282104-1, 282104-2, 282104-3
3 PIN-black/gray 282087-1, 282087-2 282105-1, 282105-2
4 PIN-black/gray 282088-1, 282088-2 282106-1, 282106-2
5 PIN-black/gray 282089-1, 282089-2 282107-1, 282107-2
6 PIN-black/gray 282090-1, 282090-2 282108-1. 282108-2
2 PIN-white 1745022-1
3 PIN-white 1745083-1 1845082-1
4 PIN-orange 1745101-1

1.5mm 2 Pin TE Automotive Connectors Housing 1

1.5mm 2 Pin TE Automotive Connectors Housing 21.5mm 2 Pin TE Automotive Connectors Housing 3
